BESV TRX URBAN 1.3 Low Step dames fiets e-bike

BESV TRX Urban 1.3 Low Step

You decide where to ride with the TRX Urban 1.3 LS. This is a comfortable and very complete bike with a low step-through frame that allows you to conquer every bike path – even if the path does not yet exist. No adventure is impossible thanks to the 630 Wh battery, the Shimano EP800 motor with 85 Nm torque, the Shimano Deore 10-speed drivetrain, the RockShox suspension fork with 120 mm travel, and the Maxxis Recon Race tires. The rear rack with Racktime Snap-it system and the high-quality LED lighting also make this e-bike a fantastic partner for all your daily rides.

Unmatched power in your pedals.

Equipped with Shimano’s absolute top drivetrain. The Shimano Steps EP800 delivers up to 85 Nm torque to your pedals – exactly when you need it.

Can take a serious beating.

With its robust aluminum fenders and extra stiff frame, you don’t have to avoid any challenge.

• 630 Wh battery capacity
• Shimano Steps EP800 with 85 Nm torque
• RockShox suspension fork

SPECIFICATIONS:

FRAMESET:

• Frame: Hardtail frame made from high-quality BESV alloy with down tube for integrated Darfon battery, with USB charging port and satellite switch on the top tube, Shimano mid-drive motor with protective cover, tapered 1.5-inch head tube, post disc mount, cold-forged dropout with replaceable hanger
• Sizes: Women: XS (43 cm) / S (47 cm) / M (52 cm) / L (56 cm)
• Color: Nickel Grey Glossy
• Fork: RockShox Recon Silver, 32 mm stanchions, TurnKey coil, 1 1/8″–1.5″ tapered aluminum steerer tube, 120 mm travel, Maxle
• Rear rack: Aluminum tubular rear rack with Snap-IT platform and spring clamp, H-Cargo rear light mounting

DRIVE UNIT:

• Motor: Shimano EP-800 mid motor, 250 W nominal power, 85 Nm torque, 25 km/h maximum assistance
• Battery: Darfon 630 Wh, integrated battery, approved for the “Shimano Service Program”, with Smart 5.6–4A charger
• Display: Shimano SC-E5003 side-mounted LCD display
• Crankset: Samox for Shimano Steps, 34T chainring with chain guard
• Bottom bracket: Shimano, integrated in the motor
• Rear derailleur: Shimano Deore, 10-speed
• Shifter: Shimano Deore, 10-speed
• Cassette: 10-speed, 11–46 teeth
• Chain: KMC e10Turbo, with quick link
• Brake set: Hydraulic disc brake set with 180 mm brake rotors front and rear
• Brake levers: Hydraulic disc brake levers, 3-finger levers

COCKPIT:

• Headset: Acros AZX-581, 1.5″ headset, angular contact bearings, integrated cable routing
• Handlebar: E-MTB riser handlebar, 6066 alloy, 15 mm rise, sweep: 7 degrees backwards, 31.8 mm clamp diameter, width in the women’s version: XS/S: 700 mm M/L: 720 mm
• Stem: 3D forged city-trekking aluminum stem, SP-Connect mount, adjustable from 0 to 90 degrees, 31.8 mm clamp diameter, integrated cable routing, width in the women’s version: XS/S: 65 mm M/L: 90 mm
• Grips: E-MTB gel grips with padding and BESV clamp
• Saddle: Selle Italia S5 Superflow
• Seatpost: Alloy 6066 with micro adjustment, 31.6 mm diameter, 3.7 mm offset
• Pedals: Wellgo, aluminum body, ball bearings

WHEELS:

• Wheels: Maxxis Recon Race, 29 × 2.25, EXO, 60 TPI wire tire

ACCESSORIES:

• Fenders: Extruded alloy fenders, front and rear 3/4 length, stainless steel fittings
• Headlight: Lezyne eBike Mini E65, 6–12 V, 65 Lux, with reflector
• Rear light: Herrmans H-Cargo, 6–12 V, with reflector
• Adjustable kickstand: Adjustable kickstand

WEIGHT:

• Bike weight: 26.80 kg
• Permissible weight: 140 kg

Fabrikant	Besv
Produktcategorie	Fiets
Maximale Bestelhoeveelheid	300
FEDAS Artikelgroep	155021
Voltage	36.00 Volt
Vermogen	250 Watt
Batterijtype	Lithium-Ion
Batterijcapaciteit / batterijvermogen	630 Wh / wattuur
Toepassingsgebied	Urban
Schorsing	Voor
Motorisering	Shimano EP 6
Framevorm / -type	MTB lage instap
Vectorgroep	Microshift XLE 10
Type circuit	Derailleur
Toelaatbaar totaal gewicht	140 kg
Fiets terugtraprem	false
Type fietsrem	Hydraulische schijfrem
Fabrikant van motorfietsen	Shimano
Type fietsframe	Wave
Fietsversnellingen	10
Gebruik van de fiets	Sport
Maximale snelheid fiets	tot 25 km/u
Type motorfiets	Mid-engine
Goedkeuring fietsstraat	true
Productfamilie	e-Bike
Productgroep	E-Urban
Product type	Volwassen fiets
Waarde wielmaat fiets	29 inch
Materiaal fietsframe	Aluminium
Geslacht	Dames|Heren|Unisex|Jeugd
Artikelbeschrijving	BESV TRX URBAN 1.3 LS stlgry/nt bk 520 M
EAN	4715109799354
EAN/UPC Typ	HE
Artikelnummer Leverancier	99.Y2U64.8MH
Siezoensjaar	2025
Seizoen	Het hele jaar door
Kleur	steel grey/night black 23
Grootte	M (52cm)
Netto-Gewicht kg	26.00 kg
Brutto-Gewicht kg	26.00 kg
